METSEPM8244 Schneider Electric PowerLogic PM8244 Power Quality Meter
METSEPM8244 Schneider Electric PowerLogic PM8244 Power Quality Meter
SKU: METSEPM8244
Condition: NEW
Couldn't load pickup availability
Backed by East Coast Compactor's 60-day warranty from the date you receive your item. See warranty details
East Coast Compactor, Corp. is not an authorized distributor of, or affiliated with, Schneider Electric. This product carries no manufacturer warranty.
Description
METSEPM8244 is a Schneider Electric PowerLogic PM8244 power quality meter from the PM8000 range. The metering base clips onto DIN rail, and a separate remote display (320 x 240 QVGA) comes with it for mounting in a panel door. It covers current, voltage, frequency, power, power factor and energy, with Class 0.2S active-energy accuracy to IEC 62053-22 and Class 0.2 to ANSI C12.20. Power quality tools include 256 samples per cycle, harmonics up to the 63rd, sag/swell detection, waveform capture and EN 50160 / IEEE 519 compliance reports. It talks Modbus TCP/IP, DNP3 and IEC 61850 over Ethernet, and Modbus RTU or ION over RS-485, and has 512 MB of memory, 3 digital inputs and 1 pulse output. Sold as 1 unit (meter base with remote display, one Schneider carton).
Specs
| Catalog number | METSEPM8244 |
| MPN | METSEPM8244 |
| Range | PowerLogic PM8000 |
| Model | PM8244 |
| Type | Power quality meter with remote display |
| Mounting | Meter base: DIN rail (clip-on); separate remote display |
| Display | Remote LCD, 320 x 240 pixels (QVGA) |
| Accuracy class | Class 0.2S active energy (IEC 62053-22); Class 0.2 (ANSI C12.20) |
| Sampling rate | 256 samples/cycle |
| Harmonics | Up to the 63rd |
| Network type | 1P + N, 3P, 3P + N |
| Frequency | 50 / 60 Hz |
| Current inputs | 1 A, 5 A or 10 A |
| Measured voltage | 57-400V AC L-N / 100-690V AC L-L |
| Control power | 90-415V AC, 50/60 Hz; 110-415V DC |
| Communication | Ethernet (Modbus TCP/IP, DNP3, IEC 61850); RS-485 (Modbus RTU, ION) |
| Digital I/O | 3 inputs / 1 pulse output |
| Memory | 512 MB |
| Protection | IP30 meter base, IP54 remote display |
| Dimensions (meter base) | 90.5 x 90.5 x 90.8 mm (3.6 x 3.6 x 3.6 in) |
| Sold as | 1 unit (meter base + remote display) |
| EAN / GTIN | 3606480701979 |
