METSEPM5563RD Schneider Electric PowerLogic PM5563 Power Meter
METSEPM5563RD Schneider Electric PowerLogic PM5563 Power Meter
SKU: METSEPM5563RD
Condition: NEW
Couldn't load pickup availability
Backed by East Coast Compactor's 60-day warranty from the date you receive your item. See warranty details
East Coast Compactor, Corp. is not an authorized distributor of, or affiliated with, Schneider Electric. This product carries no manufacturer warranty.
Description
METSEPM5563RD is a Schneider Electric PowerLogic PM5563 power meter supplied with a remote display: the meter itself mounts on DIN rail, and it comes with a separate 96 x 96 mm remote LCD display. It reads current, voltage, frequency, power factor, active and reactive power and energy, with Class 0.2S active-energy accuracy (IEC 62053-22) and harmonic analysis up to the 63rd. For networking it has an RS-485 port (Modbus RTU/ASCII) and two RJ45 Ethernet ports (Modbus TCP/IP, BACnet/IP, DNP3), plus 4 digital inputs, 2 digital outputs, 1.1 MB of memory and 52 alarms. Sold as 1 unit (meter with remote display, one Schneider carton).
Specs
| Catalog number | METSEPM5563RD |
| MPN | METSEPM5563RD |
| Range | PowerLogic PM5000 |
| Model | PM5563 |
| Type | Power meter with remote display |
| Mounting | Meter: DIN rail (clip-on), with separate remote display |
| Display | Remote LCD, 128 x 128 pixels |
| Accuracy class | Class 0.2S active energy (IEC 62053-22) |
| Harmonics | Up to the 63rd |
| Network type | 1P + N, 3P, 3P + N |
| Frequency | 50 / 60 Hz |
| Current inputs | 1 A or 5 A (CT) |
| Control power | 100-480V AC +/-10%, 50/60 Hz; 125-250V DC +/-20% |
| Communication | RS-485 (Modbus RTU/ASCII); 2 x Ethernet RJ45 (Modbus TCP/IP, BACnet/IP, DNP3) |
| Digital I/O | 4 inputs / 2 outputs |
| Memory | 1.1 MB |
| Alarms | 52 |
| Sold as | 1 unit (meter + remote display) |
| GTIN / EAN | 3606480761416 |
Related
- METSEPM5110 — PowerLogic PM5110 panel-mount power meter, Modbus RS-485
